Stereo Integrated Amplifier RA-960BX

Roland Electronics Co. Ltd., Rotel; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1992 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 307909

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 120 or 220 or 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 120 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Integrated Amplifier RA-960BX - Roland Electronics Co. Ltd.,
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 92 x 347 mm / 17.3 x 3.6 x 13.7 inch
  • Notes

  • A 2 x 60 watt hi-fi stereo integrated amplifier. Connections for two pairs of loudspeakers. Rotary controls for Bass, Treble and Volume/Balance. Rotary switches for Tone (On, Off), Recording (Phono, Tuner, Off, CD, Aux, Tape 1) and Listening (Phono, Tuner, CD, Aux, Tape 1, Tape 2). Press buttons for Power and Speaker Remote. Jack for Headphones.

    Continuous Power Output .....: 60 watts per channel min. RMS into 8 Ω
                                                      both channels driven from 20Hz to 20kHz
    Total Harmonic Distortion ..... : not > 0.3% at rated power
    Intermodulation Distortion .....: not > than 0.3% at rated power
    Damping Factor .................. : 150 (20Hz to 20kHz, 8Ω)
    Frequency Response Phono .: 20Hz - 20kHz ± 0.3dB (RIAA STD)
          CD, Tuner, Aux, Tape .....: 10Hz - 100kHz +1.0dB, -3.0dB
    Signal to Noise ratio Line .....:  95dB (IHF A Network)
                     Phono MC ........ :  70dB
                     Phono MM ........:  75dB

    Speaker impedance ............:  4Ω minimum per speaker
    Headphones Impedance ......:  8 - 2000Ω

    Versions/Power Requirements
    120 V AC 60Hz
    220 V AC 50Hz
    240 V AC 50Hz

  • Net weight (2.2 lb = 1 kg)
  • 6.2 kg / 13 lb 10.5 oz (13.656 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Technical Manual for the RA-960BX)
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Owner's Manual for the RA-960BX)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
