32G = SG32; SABA; Villingen (ID = 67939) Radio
SABA; Villingen: 32G = SG32 [Radio] ID = 67939 933x657
Select picture or schematic to display from thumbnails on the right and click for download.
For model 32G = SG32, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1931/1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: RENS1820 RENS1820 RENS1823d
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Direct Current supply (DC) / 110-220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 32G = SG32 - SABA; Villingen
Material Bakelite case
Dimensions (WHD) 310 x 220 x 200 mm / 12.2 x 8.7 x 7.9 inch
Notes [501]
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 168.00 RM +
Source of data Katalog Radio-Zentrale Prohaska 1931/32 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Mentioned in Saba-Diplomarbeit
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from SABA; Villingen
Here you find 1571 models, 1437 with images and 1062 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
