Compact System CS 3560

SABA; Villingen

  • Year
  • 1989/1990
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 287083
    • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 85
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop; ZF/IF 450/10700 kHz
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 48 W (96 W max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Compact System CS 3560 - SABA; Villingen
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 355 x 350 x 340 mm / 14 x 13.8 x 13.4 inch
  • Notes
  • 3 Band PLL Synthesizer Tuner, 16 Sender programmierbar, Doppel Cassettenteil, Plattenspieler mit Riemenantrieb, inclusive Lautsprecherboxen

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Richard Winter. See "Data change" for further contributors.
