Disco Center RCP500

SABA; Villingen

  • Year
  • 1983/1984
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 128520
    • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Disco Center RCP500 - SABA; Villingen
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 300 x 245 x 260 mm / 11.8 x 9.6 x 10.2 inch
  • Notes
  • Eingebauter Plattenspieler, 2 Geschwindigkeiten 33 und 45 Upm. Eingebautes Cassettenteil. Ausführung: Rot. Betrieb mit 2 separaten LS-Boxen.
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
