Lindau G Mod. LI-G; SABA; Villingen (ID = 197880) Radio
SABA; Villingen: Lindau G Mod. LI-G [Radio] ID = 197880 798x417
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lindau G Mod. LI-G, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1971/1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: BF185 or. BF255 BF185 or. BF255 BF237 BF237 BF237 BC239 or. BC173 or. BC149 AC126 AC188 AC187
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Lindau G Mod. LI-G - SABA; Villingen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 570 x 155 x 160 mm / 22.4 x 6.1 x 6.3 inch
Notes

Gehäusevarianten: Nussbaum hell natur, Nussbaum mitteldunkel, mattweiss.

Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Source of data Handbuch VDRG 1971/1972
Literature/Schematics (1) -- Original-techn. papers.
