Stereo FM AM Tuner MT380

SABA; Villingen

Data
Forum
Pictures
Collections

  • Year
  • 1983/1984
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 128581
    • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 27
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Stereo FM AM Tuner MT380 - SABA; Villingen
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 350 x 70 x 260 mm / 13.8 x 2.8 x 10.2 inch
  • Notes
  • Ausführung: Neusilber. Betrieb mit 2 separaten LS-Boxen Saba B 3800.
  • Source of data
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
