MW/ FM Stereo Cassette Recorder RCR 562

MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 1650790) Radio MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 1650791) Radio
MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 1650792) Radio MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 1650793) Radio
MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 1650794) Radio MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 2288142) Radio
MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 2288143) Radio MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 2288144) Radio
MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 2288145) Radio MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 2288147) Radio
Use red slider bar for more.
MW/ FM Stereo Cassette Recorder RCR 562; SABA; Villingen (ID = 1650790) Radio
SABA; Villingen: MW/ FM Stereo Cassette Recorder RCR 562 [Radio] ID = 1650790 933x459
Select picture or schematic to display from thumbnails on the right and click for download.
For model MW/ FM Stereo Cassette Recorder RCR 562, SABA; Villingen:
Cortesia proprietario

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1984 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220-230 / R14: 6 x 1,5 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: MW/ FM Stereo Cassette Recorder RCR 562 - SABA; Villingen
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 420 x 140 x 125 mm / 16.5 x 5.5 x 4.9 inch
Notes

Antena telescopica; Int. Bass Boost; Tomada para auricular; Cassette Automatic Stop.

Model page created by João-Afonso Santos. See "Data change" for further contributors.
