Phonosuper 125

Phonosuper 125; SABA; Villingen (ID = 627189) Radio

Phonosuper 125; SABA; Villingen (ID = 627190) Radio

Phonosuper 125; SABA; Villingen (ID = 627191) Radio

Phonosuper 125; SABA; Villingen (ID = 627192) Radio

Phonosuper 125; SABA; Villingen (ID = 627193) Radio

Phonosuper 125; SABA; Villingen (ID = 627194) Radio

Phonosuper 125; SABA; Villingen (ID = 627195) Radio

Phonosuper 125; SABA; Villingen (ID = 1724074) Radio
Phonosuper 125; SABA; Villingen (ID = 241032) Radio Phonosuper 125; SABA; Villingen (ID = 241035) Radio
Phonosuper 125; SABA; Villingen (ID = 241034) Radio Phonosuper 125; SABA; Villingen (ID = 241033) Radio
Phonosuper 125; SABA; Villingen (ID = 622570) Radio Phonosuper 125; SABA; Villingen (ID = 622572) Radio
Phonosuper 125; SABA; Villingen (ID = 622578) Radio Phonosuper 125; SABA; Villingen (ID = 622580) Radio
Phonosuper 125; SABA; Villingen (ID = 903639) Radio Phonosuper 125; SABA; Villingen (ID = 903640) Radio
Use red slider bar for more.
Phonosuper 125; SABA; Villingen (ID = 241032) Radio
SABA; Villingen: Phonosuper 125 [Radio] ID = 241032 933x685
Select picture or schematic to display from thumbnails on the right and click for download.
For model Phonosuper 125, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EBF89 ECL82 EM84
Semiconductors (the count is only for transistors) E250C85 RL232 RL232
Main principle Superheterodyne (common); ZF/IF 460/6750 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Phonosuper 125 - SABA; Villingen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 530 x 350 x 320 mm / 20.9 x 13.8 x 12.6 inch
Notes

Radiochassis Saba Villingen 125.
Plattenspieler PE 4230 für Normal- u. Microrille; 16, 33, 45 u. 78 Umdrehungen, Mono.

Literature/Schematics (1) -- Original-techn. papers.

Model page created by a member from D. See "Data change" for further contributors.
