Professional 1300; SABA; Villingen (ID = 563318) Speaker-P
SABA; Villingen: Professional 1300 [Speaker-P] ID = 563318 357x430
Select picture or schematic to display from thumbnails on the right and click for download.
For model Professional 1300, SABA; Villingen:
Original prospekt in 1979.

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1977–1979 Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 4 Loudspeakers
Power out 70 W (130 W max.)
from Radiomuseum.org Model: Professional 1300 - SABA; Villingen
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 375 x 600 x 305 mm / 14.8 x 23.6 x 12 inch
Notes

Saba Professional 1300

3-Weg-HiFi-Standbox mit 4 Lautsprechern. 70 Watt Nennbelastbarkeit, 130 Watt Musikbelastbarkeit, Impedanz 4 Ohm, Pegelregler für Mitten- und Hochtonbereich, Übertragungsbereich: 20-25000 Hz nach DIN 45500, Übernahmefrequenzen der Weiche 485 und 3400 Hz, Volumen 61/41 Liter Brutto/Netto.
Bestückung:

  • 1 TT 310mm Schwingspule 52mm, (Wigo PMT 310)
  • 1 Kalotten-MT 130mm Schwingspule 51mm (ITT, LPKM 130/50/120T)
  • 2 Kalotten-HT 95mm Schwingspule 26mm (Philips, AD 0162 T8)

Ausführung in Nussbaumfarben oder Metallic-Anthrazit.

Die Tieftonlautsprecher gab es, immer mit Saba Nummer (72082-009 00), in unterschiedlichen Ausführungen des Alu-Druckgußchassis.

Net weight (2.2 lb = 1 kg) 20 kg / 44 lb 0.8 oz (44.053 lb)
Price in first year of sale 648.00 DM
Source of data -- Original prospect or advert
Mentioned in Saba HiFi Programm 1977, 1978 und 1979, HiFi Jahrbuch 9

Model page created by Franz Scharner. See "Data change" for further contributors.
