RX-125
SABA; Villingen
- Country
- Germany
- Manufacturer / Brand
- SABA; Villingen
- Year
- 1992
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 168526
-
- Brand: Schwer & Söhne, GmbH
- Number of Transistors
- 2
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 220 / 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
- Power out
- 1.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RX-125 - SABA; Villingen
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 300 x 130 x 52 mm / 11.8 x 5.1 x 2 inch
- Notes
- AC/DC 4 Band Portable Radio, Frequenzbereiche: UKW 88-108 MHz, KW 6,0-18 MHz, MW 530-1600 kHz, LW 150-280 kHz, Kopfhöreranschluß (Klinke 3,5 mm), 4 tlg. Telskopantenne (60 cm), Ferritantenne (10 cm), Tonblendenschalter, 2 Transistoren im UKW-Eingang, 1 LIN-IC: TA7640AP (AM-Tuner, FM-ZF).
- Net weight (2.2 lb = 1 kg)
- 0.9 kg / 1 lb 15.7 oz (1.982 lb)
- Price in first year of sale
- 72.00 DM
- Mentioned in
- -- Original prospect or advert (Saba Gesamtkatalog 1992 Seite 53)
- Author
- Model page created by Museum Roggenhofer. See "Data change" for further contributors.
