Compact Sound Sandy

Compact Sound Sandy ; SABA; Villingen (ID = 438067) Radio Compact Sound Sandy ; SABA; Villingen (ID = 492832) Radio
Compact Sound Sandy ; SABA; Villingen (ID = 492834) Radio Compact Sound Sandy ; SABA; Villingen (ID = 2232856) Radio
Compact Sound Sandy ; SABA; Villingen (ID = 2232857) Radio Compact Sound Sandy ; SABA; Villingen (ID = 2232858) Radio
Use red slider bar for more.
Compact Sound Sandy ; SABA; Villingen (ID = 438067) Radio
SABA; Villingen: Compact Sound Sandy [Radio] ID = 438067 560x512
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact Sound Sandy, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1983/1984 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 3 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Compact Sound Sandy - SABA; Villingen
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 80 x 145 x 35 mm / 3.1 x 5.7 x 1.4 inch
Notes Ausführung: Silbermetallic, Schiefermetallic und Rot. System Compactsound, zum Anschluss der Boxen Saba CAS 2.
Source of data -- Original prospect or advert

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
