Sandy Automatic F; SABA; Villingen (ID = 866684) Radio
SABA; Villingen: Sandy Automatic F [Radio] ID = 866684 933x618
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sandy Automatic F, SABA; Villingen:
Quelle: Prospekt

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1969/1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF121 AF121 AF121 AF106 AF106 AC151 BC148 AC187 AC188 AC117
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 5 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.8 W (unknown quality)
from Radiomuseum.org Model: Sandy Automatic F - SABA; Villingen
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 165 x 75 mm / 10.6 x 6.5 x 3 inch
Notes Automatische Umschaltung von Netz- auf Batteriebetrieb bei Abnahme des Netzkabels.
Farbvarianten: brillantweiß, caramel, bahiarot, panther-schwarz.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 198.00 DM
Source of data Handbuch VDRG 1969/1970 / Radiokatalog Band 1, Ernst Erb


All listed radios etc. from SABA; Villingen
Here you find 1568 models, 1433 with images and 1062 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
