Schauinsland T181/MS

Schauinsland T181/MS; SABA; Villingen (ID = 1502553) Television

Schauinsland T181/MS; SABA; Villingen (ID = 1502554) Television
Schauinsland T181/MS; SABA; Villingen (ID = 1501617) Television
Use red slider bar for more.
Schauinsland T181/MS; SABA; Villingen (ID = 1501617) Television
SABA; Villingen: Schauinsland T181/MS [Television] ID = 1501617 500x710
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T181/MS, SABA; Villingen:
Documentation technique d'origine du fabricant SABA

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1966/1967 Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: PC900 PCF801 PCL86 EF183 PFL200 PCH200 PCC85 PCL85 PL500 PY88 DY87 A59-11W
Semiconductors (the count is only for transistors) 9:
Main principle Super-Heterodyne (Super in general)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Schauinsland T181/MS - SABA; Villingen
Material Wooden case
Shape Tablemodel, with any shape - general.
Mentioned in - - Manufacturers Literature

Model page created by Thierry Oget. See "Data change" for further contributors.
