For model Stereo Decoder E1 (EI) , USI , 14/I 14USI 12/I 12USI, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1964/1965 Category: Radio module post 1925 (not a part, not a key)
Semiconductors (the count is only for transistors) 5: AF126 AF126 AF126 AF126 AF126
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Decoder E1 , USI , 14/I 14USI 12/I 12USI - SABA; Villingen
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 95 x 120 x 35 mm / 3.7 x 4.7 x 1.4 inch
Notes Saba-Stereo-Decoder für den Einbau in verschiedenen Modellen - siehe Liste im Forumsbeitrag (je nach Typ Decoder).
11 Dioden AA119. Für 30 Hz - 16 kHz
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Collectors' prices
Source of data -- Original-techn. papers.


All listed radios etc. from SABA; Villingen
Here you find 1558 models, 1419 with images and 1041 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
SABA; Villingen: Stereo Decoder E1 , USI , 14/I 14USI 12/I 12USI
Threads: 1 | Posts: 1
Hits: 2423     Replies: 0
Saba 14USI 12/I 12USI; Stereo Decoder EI , US
Jürgen Stichling
16.Nov.03
  1 http://www.radiomuseum.org/dsp_forum_post.cfm?thread_id=11524

SABA; Villingen: Stereo Decoder E1 , USI , 14/I 14USI 12/I 12USI
