TR5907

TR5907; SABA; Villingen (ID = 2136098) Radio TR5907; SABA; Villingen (ID = 2136099) Radio
TR5907; SABA; Villingen (ID = 2136100) Radio TR5907; SABA; Villingen (ID = 2414312) Radio
TR5907; SABA; Villingen (ID = 2414313) Radio TR5907; SABA; Villingen (ID = 2414314) Radio
TR5907; SABA; Villingen (ID = 148513) Radio TR5907; SABA; Villingen (ID = 148514) Radio
TR5907; SABA; Villingen (ID = 1702989) Radio TR5907; SABA; Villingen (ID = 1702990) Radio
Use red slider bar for more.
TR5907; SABA; Villingen (ID = 2136098) Radio
SABA; Villingen: TR5907 [Radio] ID = 2136098 1400x1867
Select picture or schematic to display from thumbnails on the right and click for download.
For model TR5907, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1980 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 2:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / (3 × 1,5) Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: TR5907 - SABA; Villingen
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 75 x 133 x 38 mm / 3 x 5.2 x 1.5 inch
Notes 1 IC; Made in China.
Source of data - - Data from my own collection

Model page created by Ervé Leclercq. See "Data change" for further contributors.
