• Country
• Germany

• Manufacturer / Brand
• Sachsenwerk (bis 1945) ESWE

• Year
• 1929/1930

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 6504

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• REN1104 REN804 or REN1004 REN1104 RE134 or RES164d RGN1054

• Main principle
• TRF with regeneration; 1 Special; 2 AF stage(s)

• Tuned circuits
• 2 AM circuit(s)

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• from Radiomuseum.org
• Model: Eswe RW4 - Sachsenwerk bis 1945 ESWE

• Notes
• Röhren OK???

• Price in first year of sale
• 412.00 RM !

• Source of data
• Radiokatalog Band 1, Ernst Erb

• Circuit diagram reference
• FS-Bestückungstabelle (aber Fehler)

• Mentioned in
• Der Radio-Händler / Der Rundfunk-Händler (ab Jan. 1939) (2920)

• Picture reference
• Das Modell ist im «Radiokatalog» (Erb) abgebildet.
