Sachsenwerk Typ ESWE 343 GL 343GL

Sachsenwerk (bis 1945) ESWE

  • Year
  • 1933/1934
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 6458

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF with regeneration; 1 Special; 1 AF stage(s)
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Direct Current supply (DC)
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Sachsenwerk Typ ESWE 343 GL 343GL - Sachsenwerk bis 1945 ESWE
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 395 x 445 x 255 mm / 15.6 x 17.5 x 10 inch
  • Notes
  • Bei der einfachen Suche bitte nie Hersteller/Marke (Sachesenwerk, ESWE) eingeben. Hier haben Sachsenwerk nur erwähnt, damit Sie das wissen können (Blaue Info-Knöpfe klicken!). Sachsenwerk Typ ESWE 343 GL schreiben wir sonst Eswe 343GL, nicht Typ ESWE 343 GL. Suchen Sie nach 343 und klicken Sie auf der Trefferliste.
  • Price in first year of sale
  • 252.00 RM
  • Source of data
  • Radiokatalog Band 1, Ernst Erb
  • Circuit diagram reference
  • Lange+Schenk+FS-Röhrenbestückung
  • Picture reference
  • Das Modell ist im «Radiokatalog» (Erb) abgebildet.

 Collections | Museums | Literature

Collections

The model Sachsenwerk Typ ESWE 343 GL is part of the collections of the following members.

 Forum

Forum contributions about this model: Sachsenwerk bis 1945: Sachsenwerk Typ ESWE 343 GL 343GL

Threads: 1 | Posts: 1

Die Röhren sind in der Funkschau- Bestückungstabellen (S. 36) falsch angegeben - auch für den 343G.

Ernst Erb, 05.Dec.02
