FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3

Sangean; Chung Ho City

Data

Forum

Pictures

Collections

Country
Taiwan (Republic of China)

Manufacturer / Brand
Sangean; Chung Ho City

Year
2010

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
308702

Schematics

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363618) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (3)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363621) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (3)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363613) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363614) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363615) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363616) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 2363617) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127152) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)
Gehäuse nicht komplett.

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127153) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)
Gehäuse nicht komplett.

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127154) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127156) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)
Gehäuse nicht komplett.

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127157) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127158) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3; Sangean; Chung Ho (ID = 3127159) Radio — Sangean; Chung Ho FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
Semiconductors present.

Semiconductors

Main principle
Superheterodyne (common)

Wave bands
Broadcast (BC) and FM or UHF.

Power type and voltage
Powered by external power supply or a main unit. / 12 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: FM/MW 2-Bands PLL Synthesized Clock Radio RCR-3 - Sangean; Chung Ho City

Shape
Tablemodel with Clock ((Alarm-) Clock Radio).

Dimensions (WHD)
164 x 165 x 114 mm / 6.5 x 6.5 x 4.5 inch

Notes
- UKW-/MW-Radio mit 14 Senderspeicher
- 7 Senderspeichertasten
- Kurzschlaf-Timer und Sleep-Timer
- DCF-Funkuhr
- LC-Display beleuchtet und dimmbar
- Anzeige von Datum, Weckzeiten und Wochentag
- Snooze-Funktion
- Wecken mit ansteigendem Weckton oder Radio
- Einstellbare Alarm-Lautstärke
- Zeitzone wählbar
- Klangregelung (Höhen / Tiefen)
- AUX-Eingang (3,5 mm)
- Kopfhörer-Anschluss (3,5 mm).

Net weight (2.2 lb = 1 kg)
1 kg / 2 lb 3.2 oz (2.203 lb)

Mentioned in
-- Original-techn. papers.

Author
Model page created by Wolfgang Lill. See "Data change" for further contributors.
