Gemtone ST-6E

Gemtone ST-6E; Sanritsu Electric Co (ID = 1640363) Radio Gemtone ST-6E; Sanritsu Electric Co (ID = 801229) Radio
Gemtone ST-6E; Sanritsu Electric Co (ID = 801230) Radio Gemtone ST-6E; Sanritsu Electric Co (ID = 801231) Radio
Gemtone ST-6E; Sanritsu Electric Co (ID = 801232) Radio Gemtone ST-6E; Sanritsu Electric Co (ID = 801233) Radio
Gemtone ST-6E; Sanritsu Electric Co (ID = 801234) Radio Gemtone ST-6E; Sanritsu Electric Co (ID = 1640356) Radio
Gemtone ST-6E; Sanritsu Electric Co (ID = 1640357) Radio Gemtone ST-6E; Sanritsu Electric Co (ID = 1640358) Radio
Use red slider bar for more.
Gemtone ST-6E; Sanritsu Electric Co (ID = 1640363) Radio
Sanritsu Electric Co: Gemtone ST-6E [Radio] ID = 1640363 733x977
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gemtone ST-6E, Sanritsu Electric Co., Japan Transformer Works, Sanritz; Tokyo

Country:  Japan
Manufacturer / Brand:  Sanritsu Electric Co., Japan Transformer Works, Sanritz; Tokyo
Year: 1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out
from Radiomuseum.org Model: Gemtone ST-6E - Sanritsu Electric Co., Japan
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 62 x 104 x 34 mm / 2.4 x 4.1 x 1.3 inch
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Source of data - - Data from my own collection

Model page created by Werner Wussow. See "Data change" for further contributors.



All listed radios etc. from Sanritsu Electric Co., Japan Transformer Works, Sanritz; Tokyo
Here you find 34 models, 29 with images and 5 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
