• Country
• Japan

• Manufacturer / Brand
• Sansui Electric Co., Ltd.; Tokyo

• Year
• 1971

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 108766

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 45

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 100; 110; 117; 127; 220; 230; 240; 250 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 35 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 2000X - Sansui Electric Co., Ltd.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 460 x 150 x 335 mm / 18.1 x 5.9 x 13.2 inch

• Notes
• Als Vor-Endstufe nutzbar, Eingänge: 2× Phono, 2× Tape, Aux.

• Net weight (2.2 lb = 1 kg)
• 13.1 kg / 28 lb 13.7 oz (28.855 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
