AM/FM Stereo Receiver RZ-590

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910832) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910833) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910834) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910835) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910836) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910837) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910838) Radio

AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910839) Radio
AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910822) Radio AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910823) Radio
AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910824) Radio AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910826) Radio
AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910829) Radio
Use red slider bar for more.
AM/FM Stereo Receiver RZ-590; Sansui Electric Co., (ID = 1910822) Radio
Sansui Electric Co.,: AM/FM Stereo Receiver RZ-590 [Radio] ID = 1910822 1400x698
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM/FM Stereo Receiver RZ-590, Sansui Electric Co., Ltd.; Tokyo:
Ebay Auction

Country:  Japan
Manufacturer / Brand:  Sansui Electric Co., Ltd.; Tokyo
Year: 1992 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle PLL, Phase-locked loop
Wave bands Broadcast (BC) and FM or UHF.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 120; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out 80 W (undistorted)
from Radiomuseum.org Model: AM/FM Stereo Receiver RZ-590 - Sansui Electric Co., Ltd.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 100 x 300 mm / 16.9 x 3.9 x 11.8 inch
Notes

Sansui AM/FM Stereo Receiver Model RZ-590.
Tuning range:
FM 87,5 - 108 MHz
AM 530 - 1720 kHz
Power output: 40 watts per channel into 8Ω (stereo)
Frequency response: 40Hz to 20kHz
Total harmonic distortion: 0.2%
Signal to noise ratio: 95dB (line)
Power Requirements:
USA & Canada - 120VAC 60Hz
Others - 120/220/240VAC
Power Consumption max. 600 Watts 410VA




Net weight (2.2 lb = 1 kg) 12.1 kg / 26 lb 10.4 oz (26.652 lb)
Mentioned in - - Manufacturers Literature (Service Manual)

Model page created by Franz Scharner. See "Data change" for further contributors.
