AU7700

AU7700; Sansui Electric Co., (ID = 746288) Ampl/Mixer
AU7700; Sansui Electric Co., (ID = 2347970) Ampl/Mixer AU7700; Sansui Electric Co., (ID = 2347966) Ampl/Mixer
AU7700; Sansui Electric Co., (ID = 2347979) Ampl/Mixer AU7700; Sansui Electric Co., (ID = 2347969) Ampl/Mixer
AU7700; Sansui Electric Co., (ID = 2347962) Ampl/Mixer AU7700; Sansui Electric Co., (ID = 2347964) Ampl/Mixer
AU7700; Sansui Electric Co., (ID = 2347974) Ampl/Mixer AU7700; Sansui Electric Co., (ID = 566351) Ampl/Mixer
Use red slider bar for more.
AU7700; Sansui Electric Co., (ID = 2347970) Ampl/Mixer
Sansui Electric Co.,: AU7700 [Ampl/Mixer] ID = 2347970 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model AU7700, Sansui Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Sansui Electric Co., Ltd.; Tokyo
Year: 1975 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 108 W (unknown quality)
from Radiomuseum.org Model: AU7700 - Sansui Electric Co., Ltd.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 434 x 130 x 315 mm / 17.1 x 5.1 x 12.4 inch
Notes HiFi-Verstärker mit 2 x 54 Watt Sinus an 8 Ohm.
Net weight (2.2 lb = 1 kg) 12.3 kg / 27 lb 1.5 oz (27.093 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.



All listed radios etc. from Sansui Electric Co., Ltd.; Tokyo
Here you find 378 models, 365 with images and 114 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
