AU-666; Sansui Electric Co., (ID = 2144894) Ampl/Mixer
Sansui Electric Co.,: AU-666 [Ampl/Mixer] ID = 2144894 1400x787
Select picture or schematic to display from thumbnails on the right and click for download.
For model AU-666, Sansui Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Sansui Electric Co., Ltd.; Tokyo
Year: 1970 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 31: 2SD223 CDC9002 CDC8002 2SC871 2SC871 2SC871 2SC871 2SC871 2SC871 2SC871 2SC871 2SC871 2SC871 XA495 XA495 CDC8002 CDC8002 CDC8002 CDC8002 CDC8002 CDC8002 2SC281 2SC281 2SC708 2SC708 2SA537 2SA537 2SD188 2SD188 2SA627 2SA627
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker - This model requires external speaker(s).
Power out 70 W (unknown quality)
from Radiomuseum.org Model: AU-666 - Sansui Electric Co., Ltd.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 415 x 127 x 278 mm / 16.3 x 5 x 10.9 inch
Notes

Stereo Integrated Amplifier, 35 watts RMS per channel into 8 ohms.

Outer casing (cabinet): Wood.

Net weight (2.2 lb = 1 kg) 9.750 kg / 21 lb 7.6 oz (21.476 lb)
Price in first year of sale 1'178.00 DM

Model page created by Franz Scharner. See "Data change" for further contributors.
