Compact Disc Player CD-X711

Compact Disc Player CD-X711; Sansui Electric Co., (ID = 1936049) R-Player Compact Disc Player CD-X711; Sansui Electric Co., (ID = 1936050) R-Player
Compact Disc Player CD-X711; Sansui Electric Co., (ID = 1936052) R-Player
Use red slider bar for more.
Compact Disc Player CD-X711; Sansui Electric Co., (ID = 1936049) R-Player
Sansui Electric Co.,: Compact Disc Player CD-X711 [R-Player] ID = 1936049 1400x531
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact Disc Player CD-X711, Sansui Electric Co., Ltd.; Tokyo:
Ebay Auction

Country:  Japan
Manufacturer / Brand:  Sansui Electric Co., Ltd.; Tokyo
Year: 1989 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 230 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Compact Disc Player CD-X711 - Sansui Electric Co., Ltd.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 127.5 x 397.5 mm / 16.9 x 5 x 15.6 inch
Notes

Sansui Frontloading Single Compact Disc Player Model CD-X711
Disc format: Compact Disc, Digital Audio
Digital converter: MN6471M
CD Mechanism: KSS-152A
Frequency response: 1Hz to 20kHz
Dynamic range: 98dB
Signal to Noise Ratio: 103dB
Total harmonic distortion: 0.003%
Line output: 2V
Multi Mode Fluorescent Display
Power Requirements:
USA & Canada - 60Hz, 120 VAC
Others - 50/60Hz; 120/220-240 VAC
Power Consumption max. 35 Watts

Accessories:
Sansui Remote Control Model RS-1110 (2x 1,5V, 64x176x18mm, 140gr)

Suffix:
UL - U.S.A. Market
XX - Standard Version
CSA - Canadian Market
EU - European Market





Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 600.00 GBP
Mentioned in - - Manufacturers Literature (Service Manual)
Literature/Schematics (1) - - Manufacturers Literature (Instruction & Owners Manual)
Literature/Schematics (2) Sansui Catalogue: Collection

Model page created by Franz Scharner. See "Data change" for further contributors.



All listed radios etc. from Sansui Electric Co., Ltd.; Tokyo
Here you find 378 models, 365 with images and 114 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
