For model Digital Synthesizer Tuner TU-X501L, Sansui Electric Co., Ltd.; Tokyo:
Sansui Service Manuals

Country:  Japan
Manufacturer / Brand:  Sansui Electric Co., Ltd.; Tokyo
Year: 1987 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle PLL, Phase-locked loop
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 50/60Hz, 120/220/240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Digital Synthesizer Tuner TU-X501L - Sansui Electric Co., Ltd.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 448 x 80 x 292 mm / 17.6 x 3.1 x 11.5 inch
Notes

Sansui Digital Synthesizer Tuner Model TU-X501L.
SLDD Quartz-PLL Synthesizer Tuner
Tuning Range:
FM 87,5 - 108 MHz
AM (MW) Section: 530 - 1600 kHz
LW Section: 153 - 281 kHz
Random presets for 30 FM and AM Stations
Memory Scan
RF Mode/IF Bandwidth Selection
Power Consumption 10 Watts

See also:
Sansui Digital Synthesizer Tuner Model TU-X501 (FM, AM)

Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Mentioned in - - Manufacturers Literature (Service Manual, Instruction Manual)
Literature/Schematics (1) -- Original prospect or advert (Sansui Catalogue 'Collection')

Model page created by Franz Scharner. See "Data change" for further contributors.
