Integrated Stereo Amplifier AU-X301i

Sansui Electric Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1987 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 296396

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 130 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Integrated Stereo Amplifier AU-X301i - Sansui Electric Co., Ltd.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 136 x 311 mm / 16.9 x 5.4 x 12.2 inch
  • Notes

  • controllo volume/bass/treble/balance - filtro subsonic on/off - loudness on/off - MC Load high/low - commutatore MM/MC - presa per cuffia frontale - commutatore tape 1/2 - commutatore source/tape - commutatori speakers A/B - led protection - Tone on/off - ingressi CD/Line/Tuner/Phono - power output: 65 watts per channel into 8Ω (stereo) -frequency response: 20Hz to 20kHz -Total harmonic distortion: 0.05% - input sensitivity: 0.42mV (MC), 3.5mV (MM), 200mV (line) -signal to noise ratio: 65dB (MC), 80dB (MM), 105dB (line) - output: 200mV (line) - speaker load impedance: 4Ω to 16Ω.

  • Net weight (2.2 lb = 1 kg)
  • 9.5 kg / 20 lb 14.8 oz (20.925 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
