Quartz PLL Digital Synthesizer Tuner T-M700

Sansui Electric Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1985 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 302618

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 50 to 60 Hz, 120; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Quartz PLL Digital Synthesizer Tuner T-M700 - Sansui Electric Co., Ltd.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 340 x 37 x 207 mm / 13.4 x 1.5 x 8.1 inch
  • Notes

  • 6 AM/FM Preset Station -commutatore FM auto/mono - led ricezione FM stereo - digit rosso preset stazioni  / tasti tuning up/down/auto-manual - indicatore segnale con 3 verdi - display frontale - selettore AM channel 9 kHz/10 kHz - jack compu selector - consumo 9 watt - antenna fm 75 Ω/ 300 Ω.

    Made in Taiwan.

  • Net weight (2.2 lb = 1 kg)
  • 2.7 kg / 5 lb 15.2 oz (5.947 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
