Stereo Cassette Deck SC-3000
Sansui Electric Co., Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sansui Electric Co., Ltd.; Tokyo
- Year
- 1974–1976
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 130036
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Alternating Current supply (AC) / 100; 110; 220; 240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Stereo Cassette Deck SC-3000 - Sansui Electric Co., Ltd.;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 440 x 158 x 290 mm / 17.3 x 6.2 x 11.4 inch
- Notes
-
Sansui Stereo Cassette Deck SC 2000, silver-metallic front, standard tape: 30 - 13.000 Hz, CrO² tape: 30 - 16.000 Hz, Dolby NR; DIN, Chinch, Phono & 2 MIC-in terminals, 2 VU meters.
Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: electronically controlled DC
Tape Type: type I, CrO2
Noise Reduction: B
Frequency Response: 30Hz to 16kHz (Cr02 tape)
Signal to Noise Ratio: 60dB (dolby B)
Wow and Flutter: 0.09%
Input: 70mV (line), 0.5mV (mic)
Output: 0.3V (line)
Some models coming without wooden case with metal top cover.
- Net weight (2.2 lb = 1 kg)
- 8 kg / 17 lb 9.9 oz (17.621 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by a member from A. See "Data change" for further contributors.
