2 Band Receiver RP 6160 UM

2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2105638) Radio 2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2105641) Radio
2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2105640) Radio 2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2105639) Radio
2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2097025) Radio 2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2097026) Radio
2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2097027) Radio 2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2097028) Radio
2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2097029) Radio 2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2097030) Radio
Use red slider bar for more.
2 Band Receiver RP 6160 UM; Sanyo Electric Co. (ID = 2105638) Radio
Sanyo Electric Co.: 2 Band Receiver RP 6160 UM [Radio] ID = 2105638 1024x661
Select picture or schematic to display from thumbnails on the right and click for download.
For model 2 Band Receiver RP 6160 UM, Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1985 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 120; 220 / AA: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch
Power out
from Radiomuseum.org Model: 2 Band Receiver RP 6160 UM - Sanyo Electric Co. Ltd.;
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 220 x 125 x 70 mm / 8.7 x 4.9 x 2.8 inch
Net weight (2.2 lb = 1 kg) 0.760 kg / 1 lb 10.8 oz (1.674 lb)

Model page created by Ottmar Lauth. See "Data change" for further contributors.
