Allwave Transistor 8 8 S-P 21

Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 454085) Radio Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 454087) Radio
Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 454086) Radio Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 454088) Radio
Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 454083) Radio Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 2390704) Radio
Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 2390702) Radio Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 2390703) Radio
Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 2390701) Radio Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 263218) Radio
Use red slider bar for more.
Allwave Transistor 8 8 S-P 21; Sanyo Electric Co. (ID = 454085) Radio
Sanyo Electric Co.: Allwave Transistor 8 8 S-P 21 [Radio] ID = 454085 933x676
Select picture or schematic to display from thumbnails on the right and click for download.
For model Allwave Transistor 8 8 S-P 21, Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1962 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8:
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Allwave Transistor 8 8 S-P 21 - Sanyo Electric Co. Ltd.;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 156 x 90 x 46 mm / 6.1 x 3.5 x 1.8 inch
Notes Sanyo 8S-P21 8 transistor radio, jacks for earphone, ext.antenna, ext.speaker and 2nd earphone
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Mentioned in -- Collector info (Sammler)

Model page created by Peter Hoddow. See "Data change" for further contributors.
