All Wave Transistor 8 8SP-2N

All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 777351) Radio
All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 1620710) Radio All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 1620711) Radio
All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 1620712) Radio All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 1158028) Radio
All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 1620713) Radio
Use red slider bar for more.
All Wave Transistor 8 8SP-2N; Sanyo Electric Co. (ID = 1620710) Radio
Sanyo Electric Co.: All Wave Transistor 8 8SP-2N [Radio] ID = 1620710 900x573
Select picture or schematic to display from thumbnails on the right and click for download.
For model All Wave Transistor 8 8SP-2N, Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1965 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SA60 2SA49 2SA53 2SB54 2SB54 2SB54 2SB56 2SB56
Main principle ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / AA: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: All Wave Transistor 8 8SP-2N - Sanyo Electric Co. Ltd.;
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 155 x 90 x 45 mm / 6.1 x 3.5 x 1.8 inch
Notes

SW band 3.9-12 MHz.

Source of data -- Schematic
Circuit diagram reference Radio and TV Servicing books (R&TVS) book

Model page created by Keith Staines. See "Data change" for further contributors.
