• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1975 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 204213

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors

• Semiconductors
• LA3201 LA4101 WG1010A DS-17 DS-18

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line plus power jack, mostly with battery or storage battery / 50/60 Hz: 110; 220; 240 / 7.5 /C: 5 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.7 cm = 3 inch

• Power out
• 1 W (max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Portable Cassette Recorder M-2522E and M-2522Z - Sanyo Electric Co. Ltd.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 140 x 260 x 70 mm / 5.5 x 10.2 x 2.8 inch

• Notes

• Changes in M-2522E(x)

  • Diode DS-18 used in this model only
  • mains 220VAC 50Hz

• Net weight (2.2 lb = 1 kg)
• 1.450 kg / 3 lb 3.1 oz (3.194 lb)

• Source of data
• -- Original prospect or advert

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
