FM SW MW LW Cassette M2440LE CHV

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

  • Year
  • 1975 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 274413

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 220 / 4 x 1,5 / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: FM SW MW LW Cassette M2440LE CHV - Sanyo Electric Co. Ltd.;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 370 x 260 x 87 mm / 14.6 x 10.2 x 3.4 inch
  • Notes
  • Mono- Radio Rekorder mit Kassettenteil, audio stop, eingebautes Kondensatormikrofon, Counter, Indicator VU - Batterie.
    Externer Anschluß für 6 Volt Gleichstrom Autobatterie, sonst Betrieb am 220 Volt Netz oder mit 4 x 1,5 V Monozellen.
    Externer Lautsprecherausgang 8 Ohm.
    Umschalter; Hi - Lo und Beat - Cancel. DIN- Überspielbuchse, Anschluß für Aussenmikrofon und Stereoeingang. Das Gerät wurde für den Osteuropäischen Markt produziert.
    Es hat OIRT UKW- Bereich von 66...74 Mhz und KW von 6,0 bis 18,00 MHz .


  • Author
  • Model page created by Wolfgang Lill. See "Data change" for further contributors.
