FM/MW/SW 8 Band Receiver RP 8900

FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305519) Radio FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305518) Radio
FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305520) Radio FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305513) Radio
FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305514) Radio FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305515) Radio
FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305516) Radio FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305517) Radio
FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305521) Radio
Use red slider bar for more.
FM/MW/SW 8 Band Receiver RP 8900; Sanyo Electric Co. (ID = 2305519) Radio
Sanyo Electric Co.: FM/MW/SW 8 Band Receiver RP 8900 [Radio] ID = 2305519 1400x1088
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM/MW/SW 8 Band Receiver RP 8900, Sanyo Electric Co. Ltd.; Moriguchi (Osaka):
Quelle: Ebay photo.Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány (radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1980 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common); ZF/IF 455/10800 kHz
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / AA: 4 × 1,5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.7 cm = 3 inch
Power out 0.4 W (0.6 W max.)
from Radiomuseum.org Model: FM/MW/SW 8 Band Receiver RP 8900 - Sanyo Electric Co. Ltd.;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 182 x 110 x 37 mm / 7.2 x 4.3 x 1.5 inch
Net weight (2.2 lb = 1 kg) 0.450 kg / 0 lb 15.9 oz (0.991 lb)
Mentioned in -- Original-techn. papers.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
