• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1975 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 215992

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 38

• Semiconductors
• 2SK41 2SK44 2SC668 2SC930 2SC536 2SC929 2SC537 2SC693 2SA733 2SC875 2SC1175 2SA532 2SD325 2SB509 LA1201 LA3300 1S188 10D-1 10DC-1 10DC-1R DS442 SZ9

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 120; 200; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 36 W (75 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo Receiver DCX-4000L - Sanyo Electric Co. Ltd.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 455 x 148 x 340 mm / 17.9 x 5.8 x 13.4 inch

• Net weight (2.2 lb = 1 kg)
• 9.3 kg / 20 lb 7.8 oz (20.485 lb)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Jérôme Careglio. See "Data change" for further contributors.
