Solid State 4 Channel Stereo DC-620XKC

Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Data
Forum
Pictures
Collections

  • Year
  • 1973 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 352570

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 19
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz; 3 AF stage(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 50/60 Hz, 120; 200; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 16 W (30 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Solid State 4 Channel Stereo DC-620XKC - Sanyo Electric Co. Ltd.;
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 587 x 133 x 310 mm / 23.1 x 5.2 x 12.2 inch
  • Notes

  • Sanyo Model DC620XKC

    4-channel surround console with 2-band radio tuner.

    Features: AM/FM tuner; 40 watts P.M.P.; 8" woofer and 2½" tweeter; sealed type front speaker enclosure; 3-speed (manual says 4) auto changer BSR C-123 with ceramic stereo cartridge CZ200 and Sapphire stylus; 10" platter; slide bass, treble, balance and volume controls, with separate volume control for mic. mixing. Headphone jack.

    Speaker unit dimensions: 18-¾" x 25" x 13-¾". Weight 12 kg each.

    SX-812 rear speakers (optional) to suit DC620XKC; 6½" twin cone, heavy duty hermetically sealed speaker enclosures ($42). (MINGAY'S PRICE SERVICE)

  • Net weight (2.2 lb = 1 kg)
  • 19 kg / 41 lb 13.6 oz (41.85 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
