Video Camera Recorder 8 Top D5 VM-D5P

• Country
• Japan

• Manufacturer / Brand
• Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

• Year
• 1988 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 336545

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6-7,5 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Video Camera Recorder 8 Top D5 VM-D5P - Sanyo Electric Co. Ltd.;

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 110 x 134 x 351 mm / 4.3 x 5.3 x 13.8 inch

• Notes

• Sanyo Video Camera Recorder 8 Top D5 VM-D5P

  • Video-8 system
  • Video recording: Rotating 2-head helical-scan FM, color under system
  • Audio recording: Rotating head FM system
  • PAL color CCIR standard
  • CCD solid state image converter
  • 0.7" electronic view finder (B/W)
  • Omnidirectional electret condenser microphone
  • Electro-powered 6x zoom lens f = 12 - 72 mm, F 1.6, automatic focus.

  AV terminal: Video input and output, 1 V_ss, 75 Ω, unbalanced, negative sync. Audio input and output, -6 dBs, 47 kΩ resp. 2.2 kΩ or less. Microphone and earphone jack.

  Weight without battery and cassette.

• Net weight (2.2 lb = 1 kg)
• 2.4 lb (2 lb 6.4 oz) / 1.090 kg
