Marine 8-34
Sargent Co., E.M.; Oakland, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sargent Co., E.M.; Oakland, CA
- Year
- 1934/1935 ??
- Category
- Commercial Receiver (may include amateur bands)
- Radiomuseum.org ID
- 127367
By courtesy of "antiqueradios.com"!
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- - For headphones or amp.
- Power out
- 3 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Marine 8-34 - Sargent Co., E.M.; Oakland, CA
- Shape
- Tablemodel, with any shape - general.
- Notes
- Coverage: 0.2 to 20MHz in four bands. Two IF stages, BFO; three wire antenna in, bal/unbal; antenna trimmer. Differs from the standard 8-34 for the band coverage.
- Price in first year of sale
- 58.00 $
- Source of data
- Communications Receivers
- Author
- Model page created by Emilio Ciardiello. See "Data change" for further contributors.
