723-504; Sarkes Tarzian (ID = 844237) Radio
Sarkes Tarzian: 723-504 [Radio] ID = 844237 933x530
Select picture or schematic to display from thumbnails on the right and click for download.
For model 723-504, Sarkes Tarzian Enterprises, Bloomington, In:
Front View

Country:  United States of America (USA)
Manufacturer / Brand:  Sarkes Tarzian Enterprises, Bloomington, In
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 19CL8A 19EA8 12BN6 35EH5 35W4
schematic requested
Main principle Superhet with RF-stage
Tuned circuits 7 AM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage AC/DC-set / 110 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out
from Radiomuseum.org Model: 723-504 - Sarkes Tarzian Enterprises,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 10 x 6 x 4.75 inch / 254 x 152 x 121 mm
Notes Model 723-504 from Sarkes Tarzian Enterprises, Bloomington, In. uses the 12BN6 as the FM detector.
Net weight (2.2 lb = 1 kg) 4 lb (4 lb 0 oz) / 1.816 kg

Model page created by Tom Guest. See "Data change" for further contributors.
