Stabilock 4010A; Schlumberger; (ID = 332525) Equipment
Schlumberger;: Stabilock 4010A [Equipment] ID = 332525 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stabilock 4010A, Schlumberger; (international)

Country:  Worldwide
Manufacturer / Brand:  Schlumberger; (international)
Year: 1976 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stabilock 4010A - Schlumberger; international
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 443 x 264 x 374 mm / 17.4 x 10.4 x 14.7 inch
Notes Dieser Funkmessplatz beinhaltet einen hochkonstanten Messsender der mit exakten Pegeln in AM/FM intern und extern modulierbar ist, einen Funkempfänger, Frequenzzähler, NF-Generator, NF- Millivoltmeter, Hub-Messer für FM-Sender, Modulationsgradmesser für AM-Sender und ein Sendeleistungsmessgerät.
Frequenzbereich: 10 kHz-200 MHz und 200 MHz-480 MHz dekadisch einstellbar in 100-Hz-Schritten mit zusätzlicher Feinverstimmung.
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Source of data - - Data from my own collection

Model page created by Dieter Barkawitz. See "Data change" for further contributors.



All listed radios etc. from Schlumberger; (international)
Here you find 32 models, 30 with images and 12 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Schlumberger;: Stabilock 4010A
Threads: 1 | Posts: 1
Hits: 2657     Replies: 0
Schlumberger Stabilock 4010A /4022
Don Brown
07.Nov.08
  1

I am trying to restore my beautifully built Stabilock 4010A I need circuits of the Synth oscillators I downloaded some details from the site but they where a German version of the ops handbook that I have,  but it only has block diagrams. I have got most of the unit going its just needs the PLL's and oscillators aligned

Regards

Don
