800B + 800B-FM

• Country
• United States of America (USA)

• Manufacturer / Brand
• Scott Radio Labs.(E.H., Transformer); Chicago (IL)

• Year
• 1946/1947

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 55357

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 24

• Valves / Tubes
• 6SK7GT 6J5 6SA7GT 6SK7GT 6SK7GT 6H6GT 6E5 6AG5 6C4 6AG5 6AC7 6AC7 6SJ7 6SJ7 6H6 6E5 6J5GT 6J5GT 6SL7GT 6L6G 6L6G 5Y3GT 5Y3GT 0D3

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Material
• Wooden case

• from Radiomuseum.org
• Model: 800B + 800B-FM - Scott Radio Labs.E.H.,

• Shape
• Console with any shape - in general

• Notes

• The Scott model 800-B is an AC Operated FM-AM Combination Radio-Phono Superheterodyne Receiver with Automatic Pushbutton Tuning and Self Contained Loop Antennas. Used in several cabinets, e.g. Modern , Georgian , or Chippendale.

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 15 = 1947 and before

• Mentioned in
• E.H.Scott Radio Collectors Guide (1925-1946)

• Literature/Schematics (1)
• Collector's Guide to Antique Radios (6th edition) (see also SAMS Photofact, Date: Feb 1947, Set 14, Folder 474-27)

• Other Models

• Here you find 198 models, 122 with images and 48 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
