Silvertone 6492 Ch= 101.566 (-2A) to (-2E)

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1939/1940
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 55483
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / 105-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 4 inch = 10.2 cm
  • Power out
  • 1.3 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone 6492 Ch= 101.566 to - Sears, Roebuck & Co.; Chicago
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 16 x 26 x 14 inch / 406 x 660 x 356 mm
  • Notes

  • Typical Sheraton piece actually taken from the original design which is typical of small tables in general use during the latter part of the 18th Century. Built in loop antenna. Tuning Band 550 to 1600 kc.

  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 11 = ca. 1940 and before
  • Literature/Schematics (1)
  • Riders 11-85, 86
