Silvertone 1506
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1931/1932
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 55854
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / Either 25 cycle, 110V or 60 cycle, 110V or 60 cycle, 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: Silvertone 1506 - Sears, Roebuck & Co.; Chicago
- Notes
-
The Sears Silvertone 1506 is an AC operated 6 tube BC band receiver.
See details and summaries about Sears catalogs etc. According to the Sears Silvertone Service Manual (Which was published in May, 1937), the original manufacturer of this model was no longer in business and thus, Source Number 118 took over the service of supply of replacement parts. The original manufacturer is unknown. Parts supplied for this model by Wholesale Radio Service Co., New York, NY (Sears Manufacturer Source Number Code 118).
The chassis and schematic used for this model is also used in model Silvertone 7049.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 6 = 1935 and before
- Literature/Schematics (1)
- Rider's Perpetual, Volume 6 = 1935 and before (Riders 6-5, 6-6)
- Literature/Schematics (2)
- Silvertone Radios, Service Inf. 1928 thru 1936 (Pages 235 to 236)
- Other Models
-
Here you find 5471 models, 3201 with images and 4174 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sears, Roebuck & Co.; Chicago (IL)
