Silvertone 1585 7-Tube All-Electric Order= 57KM 1585

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267224) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267225) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267226) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267227) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267228) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267229) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267230) Radio

Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1267231) Radio
Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266648) Radio Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266652) Radio
Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266653) Radio Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266656) Radio
Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266655) Radio Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 195605) Radio
Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 528198) Radio Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1263138) Radio
Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 528200) Radio Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266651) Radio
Use red slider bar for more.
Silvertone 1585 7-Tube All-Electric Order= 57KM 1585; Sears, Roebuck & Co. (ID = 1266648) Radio
Sears, Roebuck & Co.: Silvertone 1585 7-Tube All-Electric Order= 57KM 1585 [Radio] ID = 1266648 757x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 1585 7-Tube All-Electric Order= 57KM 1585, Sears, Roebuck & Co.; Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1932/1933 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 56 58 or 57 or 24 58 58 57 or 24 47 80
Main principle Superheterodyne (common); ZF/IF 175 kHz; 2 AF stage(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10 inch = 25.4 cm
Power out
from Radiomuseum.org Model: Silvertone 1585 7-Tube All-Electric Order= 57KM 1585 - Sears, Roebuck & Co.; Chicago
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Dimensions (WHD) 14.3 x 17.8 x 10.4 inch / 363 x 452 x 264 mm
Notes The Sears Silvertone 1585 has a "Micro-Vision Triple Scale Dial". This is a moving scale AND a moving pointer that move in opposite directions! The loudspeaker has a hum bucking coil. Has a 3-gang tuning condenser but no RF stage - and reduced number of IF circuits depending on schematic version (referred to as a "self-tuned" IF output transformer). The model 1585 could be ordered for 25 cycle line power without any additional cost. The Silvertone console 1587 and the cathedral 1585 share the same chassis / schematic - see list below. Catalog states: "For long and short wave reception" , however this statement is incorrect and the model actually has the broadcast and two SW bands - see more details in this link. This model is a domestic version and the mains transformer has no taps. But there is also a "Universal transformer" for 40 to 60 cycle available with taps: 115, 130, 155 and 230 volts. Walnut finished cabinet with matched oriental wood instrument panel with Tamo wood overlay decorations across the top. Decorative pilaster side posts. The knobs are: top left is "Volume", below left is "3 tap Band Switch", center "Station Selector", top right is "Tone" and below right is the "ON-OFF Switch".
Order number 57KM 1585 1/4 with tubes for $ 37.50 or for easy payment: $ 5 "down" cash and $ 5 per month until paid $ 41.25. See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101). In fact it is the schematic of Colonial model 62. But within the same model family there were quite a few changes made which are explained in the original Sears documentation included with the schematics. Even the tubes could be different (see plan "B"). The schematics are officially for models 1580, 1582, 1584, 1585, 1586, 1588, 1589, 7100, but model 1587 is also part of this model family and there are possibly others.
Price in first year of sale 37.50 $
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965 (Cathedral and Tombstone Radios, Stein. Page 236.)
Literature/Schematics (1) The Sears Silvertone Catalogs 1930-1942 (page 54)
Literature/Schematics (2) Sears, Roebuck Catalogs (Silvertone) (#165, Fall & Winter 1932/33, page 476.)
Literature/Schematics (3) Silvertone Radios, Service Inf. 1928 thru 1936 (Pages 245 - 252)
Literature/Schematics (4) Machine Age to Jet Age II (page 256.)


All listed radios etc. from Sears, Roebuck & Co.; Chicago (IL)
Here you find 5102 models, 3092 with images and 3664 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
