Silvertone 1932-A
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 56042
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 175 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Dry Batteries / 135 & 3 Volt
- Loudspeaker
- Magnetic loudspeaker (reed) generic.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 1932-A - Sears, Roebuck & Co.; Chicago
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 36.5 x 22.3 x 11.5 inch / 927 x 566 x 292 mm
- Notes
- Wrong model is shown in the "Machine Age to J.Vol.2 Stein 97".
- Price in first year of sale
- 40.00 $
- External source of data
- Ernst Erb
- Source of data
- Machine Age to Jet Age II
- Circuit diagram reference
- Rider's Perpetual, Volume 6 = 1935 and before
- Mentioned in
- Pre-War Consoles
- Literature/Schematics (1)
- The Sears Silvertone Catalogs 1930-1942 (Riders 6-48, 49)
