Silvertone 4608A Ch= 101.472X

Sears, Roebuck & Co.; Chicago (IL)

  • Year
  • 1938
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 56391
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz
  • Tuned circuits
  • 8 AM circuit(s)
  • Wave bands
  • Broadcast, Short Wave(s) and Police.
  • Power type and voltage
  • Storage and/or dry batteries / 90 & 4 or 4.5 & 3 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
  • Power out
  • 0.9 W (unknown quality)
  • from Radiomuseum.org
  • Model: Silvertone 4608A Ch= 101.472X - Sears, Roebuck & Co.; Chicago
  • Notes
  • Speaker 6 or 8 inch. Presence of Bias Cells.
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 10 = 1939 and before
  • Literature/Schematics (1)
  • Riders 10-3, 4
