Silvertone 4680 Order= 57VM 4680 or 57HM 4680 Ch= 101454

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1937/1938
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 56440
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 10
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast, Short Wave(s) and Police.
  • Power type and voltage
  • Alternating Current supply (AC) / 50 or 60 cycles, 105-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
  • Power out
  • 10 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone 4680 Order= 57VM 4680 or 57HM 4680 Ch= 101454 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 22.5 x 37.25 x 12.5 inch / 572 x 946 x 318 mm
  • Notes

  • The Sears Silvertone 4680 is an AC operated, 8 tube BC, police and SW band receiver.

    It has 3 tuning bands: SW from 1.7 to 6 MC, Foreign from 5.8 to 18 MC and Broadcast from 545 to 1800 kC.

    In the 1937 winter catalog, the model has the order no. 57VM 4680.

  • Price in first year of sale
  • 51.85 $
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 9 = 1938 and before
  • Literature/Schematics (1)
  • Riders 9-56 to 58
