Silvertone Order= 57FM 4686 Ch= 101.483

Silvertone Order= 57FM 4686 Ch= 101.483; Sears, Roebuck & Co. (ID = 642792) Radio

Silvertone Order= 57FM 4686 Ch= 101.483; Sears, Roebuck & Co. (ID = 642793) Radio
Silvertone Order= 57FM 4686 Ch= 101.483; Sears, Roebuck & Co. (ID = 713391) Radio Silvertone Order= 57FM 4686 Ch= 101.483; Sears, Roebuck & Co. (ID = 1275942) Radio
Silvertone Order= 57FM 4686 Ch= 101.483; Sears, Roebuck & Co. (ID = 2376633) Radio
Use red slider bar for more.
Silvertone Order= 57FM 4686 Ch= 101.483; Sears, Roebuck & Co. (ID = 713391) Radio
Sears, Roebuck & Co.: Silvertone Order= 57FM 4686 Ch= 101.483 [Radio] ID = 713391 439x713
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone Order= 57FM 4686 Ch= 101.483, Sears, Roebuck & Co.; Chicago (IL):
Image Courtesy of Mark V. Stein for Radiomuseum.org use only.

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6K7G 6A8G 6Q7G 6K7G 6U5 6Q7G 6J5G 6V6G 6V6G 5Y3G
Main principle Superhet with RF-stage; ZF/IF 465 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 12 inch = 30.5 cm
Power out 10 W (unknown quality)
from Radiomuseum.org Model: Silvertone Order= 57FM 4686 Ch= 101.483 - Sears, Roebuck & Co.; Chicago
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes Speaker 6,8,10 or 12 inch. Automatic tuning.
Price in first year of sale 59.95 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 14 = 1944 = before 1943
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) Pre-War Consoles (Riders 14-7, 8)
Literature/Schematics (2) The Sears Silvertone Catalogs 1930-1942 (page 126)
Literature/Schematics (3) Sears, Roebuck Catalogs (Silvertone) (# 175, Fall & Winter 1937/38, page 658.)
