Silvertone 6287 Ch= 528.6287
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1953
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 56778
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6.3 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 1.25 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Silvertone 6287 Ch= 528.6287 - Sears, Roebuck & Co.; Chicago
- Shape
- Chassis only or for «building in»
- Notes
- The Silvertone 6287 with chassis 528.6287 uses a vibrator for +B. The model Silvertone 6287 was also sold as brand "Allstate 6287-4" by Sears, Roebuck & Co. - according to Howard W. Sams & Co, Date 12-53 Set 225 Folder 3.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 22, covering 1951
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 12-53, set 225, folder 3.)
