Silvertone 7006 Ch= 132.39900
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1956
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 82446
-
- Brand: Silvertone
Scanned from the Sears Catalog page 866.
Scanned from the Sears Catalog page 866.
Sams Photofact Folders
picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 110 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Silvertone 7006 Ch= 132.39900 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 12.75 x 6.25 x 5.5 inch / 324 x 159 x 140 mm
- Notes
-
The Sears Silvertone 7006 is an AC/DC operated 5 tube AM band receiver. The AM band frequency tuning range is 535-1620kHz.
The following models use the same schematic and cabinets but have different cabinet colors:
Model Cabinet Colors 7006 Brown 7007 Ivory 7008 Aqua See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Noblitt-Sparks Ind. (Arvin), Columbus, Indiana (Sears Manufacturer Source Number Code 132).
- Price in first year of sale
- 18.95 $
- Source of data
- Machine Age to Jet Age II
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 17, 1957
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 1-57, Set 345, Folder 15)
- Literature/Schematics (2)
- Beitman Radio Diagrams, Vol. 17, 1957 (Page 11)
- Literature/Schematics (3)
- Sears, Roebuck Catalogs (Silvertone) (page 866)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
- Other Models
-
Here you find 5467 models, 3201 with images and 4173 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sears, Roebuck & Co.; Chicago (IL)
Forum contributions about this model: Sears, Roebuck & Co.: Silvertone 7006 Ch= 132.39900
Threads: 1 | Posts: 2
Hello I'm currently working on a silvertone 7006 and have been coming across several problems. First of all, the lower half of the dial (55-90) isn"t getting anything but quiet static. Next the upper half gets about 5 stations but they are so covered up with loud static I can't even understand them. I'm rather new to restoring my radios so anything helps. I've considerd replacing the capacitors but they look ok and it doesn't have any old paper capcitors. I'm also working on aligning the radio but this doesn't seem to be working either, and by the way I know that I should be getting a station or two on the lower half of the dial, my area has a couple like: am 560. Thanks, Alec
Alec Anglum, 21.Sep.13
